Appendix
A.2 Data tables
SIRIUS 3RW5 Modbus TCP communication module
Manual, 03/2018, A5E43676481002A/RS-AA/001
87
A.2.16
Statistic data
Only read access (r) to the statistical data is possible via Function Codes 03 and 04. The
data table "Statistic data" is not supported by the 3RW52 soft starter.
Register
Byte
Data format
Statistic data
Range of values
Increment
3RW55
1)
Address
high / low
0x8C01
high
Unsigned8
Phase current max (%)
0 … 796.9 %
3.125 %
r
0x8C02
high
Unsigned16
Last tripping current IA (%)
0 … 1 000 %
3.125 %
r
0x8C03 high Unsigned32 Operating hours - device 0 …
4 294 967 295 s
1 s r
0x8C05
high
Unsigned32
Number of starts motor CW
0 … 4 294 967 295
1
r
0x8C07
high
Unsigned32
Number of starts motor CCW
0 … 4 294 967 295
1
r
0x8C09
high
Unsigned16
Number of motor overload trips
0 … 65 535
1
r
0x8C0B
high
Signed32
Maximum phase current (rms)
-20 000 … 20 000 A
0.01 A
r
0x8C0D
high
Signed32
Last tripping current IA (rms)
-20 000 … 20 000 A
0.01 A
r
0x8C0F high Unsigned32 Operating hours - motor 0 …
4 294 967 295 s
1 s r
0x8C11 high Unsigned32 Operating hours - motor current =
18 ... 49.9% x Iemax
0 …
4 294 967 295 s
1 s r
0x8C13 high Unsigned32 Operating hours - motor current =
50 ... 89.9% x Iemax
0 …
4 294 967 295 s
1 s r
0x8C15 high Unsigned32 Operating hours - motor current =
90 ... 119.9% x Iemax
0 …
4 294 967 295 s
1 s r
0x8C17 high Unsigned32 Operating hours - motor current =
120 ... 1000% x Iemax
0 …
4 294 967 295 s
1 s r
0x8C1A high Unsigned16 Number of switching element overload
trips
0 … 65 535 1 r
0x8C1B
high
Unsigned16
Number of bypass overload trips
0 … 65 535
1
r
0x8C1F high Unsigned32 Number of electrical braking stops 0 … 4 294 967 295 1 r
0x8C21
high
Unsigned32
Number of starts output 1
0 … 4 294 967 295
1
r
0x8C23 high Unsigned32 Number of starts output 2 0 … 4 294 967 295 1 r
0x8C25
high
Unsigned32
Number of starts output 3
0 … 4 294 967 295
1
r
0x8C27
high
Unsigned32
Number of starts output 4
0 … 4 294 967 295
1
r
0x8C3B high Unsigned64 Active energy import (total) 0 …
4 294 967 295 Ws
1 Ws r
0x8C3F high Unsigned64 Active energy export (total) 0 …
4 294 967 295 Ws
1 Ws r
0x8C43
high
Unsigned16
Last real starting time
0 … 1 000 s
0.1 s
r
1)
Supported by SIRIUS 3RW55 soft starter
