Appendix
A.2 Data tables
SIRIUS 3RW5 Modbus TCP communication module
Manual, 03/2018, A5E43676481002A/RS-AA/001
89
A.2.18
Parameters
Read access (r) to the parameters is possible via Function Codes 03 and 04. Write access
(w) is possible for individual parameters via function codes 06 and 16.
Register
Byte
Data format
[Obj. No.]
Parameters
Range of values
[encoding]
Increment
3RW
Address
high / low
52
1)
[D*]
55
2)
[D*]
0x9401 high Bit4
[2313]
Automatic parameterization
[0 ... 2]
- - r/w
[0]
[0] Off
[1] ON - with preset
starting time
[2] ON - with preset
starting time and current
limit
0x9402 high Unsigned16
[2315]
Preset starting time 0 … 360 s
[0 … 3 600]
0.1 s - r/w
[100]
0x9403 high Unsigned32
[130]
Rated operational current Ie
-
0.01 A
r
r/w
SIRIUS 3RW55 soft starter,
High Feature, 13 A, 3-phase
controlled, motor overload
protection, torque control
2.5 … 22.5 A
[250 … 2 250]
0.01 A - [250]
SIRIUS 3RW55 soft starter,
High Feature, 18 A, 3-phase
controlled, motor overload
protection, torque control
3.5 … 31.1 A
[350 … 3 110]
0.01 A - [350]
SIRIUS 3RW55 soft starter,
High Feature, 25 A, 3-phase
controlled, motor overload
protection, torque control
5 … 43.3 A
[500 … 4 330]
0.01 A - [500]
SIRIUS 3RW55 soft starter,
High Feature, 32 A, 3-phase
controlled, motor overload
protection, torque control
6.5 … 55.4 A
[650 … 5 540]
0.01 A - [650]
SIRIUS 3RW55 soft starter,
High Feature, 38 A, 3-phase
controlled, motor overload
protection, torque control
7.5 … 65.8 A
[750 … 6 580]
0.01 A - [750]
SIRIUS 3RW55 soft starter,
High Feature, 25 A / 690 V,
3-phase controlled, motor
overload protection, torque
control
5 … 43.3 A
[500 … 4 330]
0.01 A - [500]
SIRIUS 3RW55 soft starter,
High Feature, 47 A, 3-phase
controlled, motor overload
protection, torque control
10 … 81.4 A
[1 000 … 8 140]
0.01 A - [1 000]
SIRIUS 3RW55 soft starter,
High Feature, 63 A, 3-phase
controlled, motor overload
protection, torque control
13 … 109 A
[1 300 … 10 900]
0.01 A - [1 300]
