Siemens SIRIUS 3RW5 series User Manual

Appendix
A.2 Data tables
SIRIUS 3RW5 Modbus TCP communication module
88 Manual, 03/2018, A5E43676481002A/RS-AA/001
A.2.17
Maximum pointer
Only read access (r) to the maximum pointers is possible via Function Codes 03 and 04. The
data table "Maximum pointers" is not supported by the 3RW52 soft starter.
Register
Byte
Data format
Maximum pointer
Range of values
Increment
3RW55
1)
Address
high / low
0x9001
high
Unsigned8
Minimum phase current I L1 (%)
0 … 796.9 %
3.125 %
r
low
Unsigned8
Phase current I L2 min (%)
0 … 796.9 %
3.125 %
r
0x9002
high
Unsigned8
Phase current I L3 min (%)
0 … 796.9 %
3.125 %
r
0x9003
high
Unsigned8
Maximum phase current I L1 (%)
0 … 796.9 %
3.125 %
r
low Unsigned8 Phase current I L2 max (%) 0 … 796.9 % 3.125 % r
0x9004
high
Unsigned8
Phase current I L3 max (%)
0 … 796.9 %
3.125 %
r
0x9005
high
Unsigned16
Maximum trigger current
0 … 1000 %
3.125 %
r
0x9006
high
Unsigned16
Number of motor overload trips
0 … 65 535
1
r
0x9007
high
Signed32
Maximum trigger current
-20 000 … 20 000 A
0.01 A
r
0x9009
high
Signed32
Minimum phase current I L1 (rms)
-20 000 … 20 000 A
0.01 A
r
0x900B
high
Signed32
Phase current I L2 min (rms)
-20 000 … 20 000 A
0.01 A
r
0x900D
high
Signed32
Phase current I L3 min (rms)
-20 000 … 20 000 A
0.01 A
r
0x900F
high
Signed32
Maximum phase current I L1 (rms)
-20 000 … 20 000 A
0.01 A
r
0x9011
high
Signed32
Phase current I L2 max (rms)
-20 000 … 20 000 A
0.01 A
r
0x9013
high
Signed32
Phase current I L3 max (rms)
-20 000 … 20 000 A
0.01 A
r
0x9015
high
Unsigned16
Line-to-line voltage U L1-L2 min
0 … 1 500 V
0.1 V
r
0x9016
high
Unsigned16
Line-to-line voltage U L2-L3 min
0 … 1 500 V
0.1 V
r
0x9017
high
Unsigned16
Line-to-line voltage U L3-L1 min
0 … 1 500 V
0.1 V
r
0x9018
high
Unsigned16
Line-to-line voltage U L1-L2 max
0 … 1 500 V
0.1 V
r
0x9019
high
Unsigned16
Line-to-line voltage U L2-L3 max
0 … 1 500 V
0.1 V
r
0x901A
high
Unsigned16
Line-to-line voltage U L3-L1 max
0 … 1 500 V
0.1 V
r
0x901D
low
Unsigned8
Maximum switching element heating
0 … 250 %
1 %
r
0x901E
high
Unsigned8
Minimum line frequency
0 … 100 Hz
0.5 Hz
r
low Unsigned8 Maximum line frequency 0 … 100 Hz 0.5 Hz r
0x901F high Unsigned32 Operating hours - motor current =
18 ... 49.9% x Ie
0 … 4 294 967 295 s 1 s r
0x9021 high Unsigned32 Operating hours - motor current =
50 ... 89.9% x Ie
0 … 4 294 967 295 s 1 s r
0x9023 high Unsigned32 Operating hours - motor current =
90...119.9% x Ie
0 … 4 294 967 295 s 1 s r
0x9025 high Unsigned32 Operating hours - motor current =
120...1000% x Ie
0 … 4 294 967 295 s 1 s r
0x9027
high
Unsigned32
Operating hours - device
0 … 4 294 967 295 s
1 s
r
0x902B
high
Signed32
Starting current I max (rms)
-20 000 … 20 000 A
0.01 A
r
0x902D
high
Signed32
Starting current I L1 max (rms)
-20 000 … 20 000 A
0.01 A
r
0x902F
high
Signed32
Starting current I L2 max (rms)
-20 000 … 20 000 A
0.01 A
r
0x9031
high
Signed32
Starting current I L3 max (rms)
-20 000 … 20 000 A
0.01 A
r
1)
Supported by SIRIUS 3RW55 soft starter
