Appendix
A.2 Data tables
SIRIUS 3RW5 Modbus TCP communication module
Manual, 03/2018, A5E43676481002A/RS-AA/001
83
Register
Byte
Bit address
Data format
Soft starter diagnostics
3RW
Address
high / low
52
1)
55
2)
low
0x8438
Bool
Bus error
r
r
0x8439
Bool
CPU/Master STOP
r
r
0x843A Bool Automatic mode r r
0x843B
Bool
Operating mode manual
r
r
0x843C
Bool
Manual operation local
r
r
0x843E
Bool
Connection abort in manual mode
r
r
0x843F
Bool
Error process image
-
r
0x8404 high
0x8440
Bool
Parameter assignment active
-
r
0x8441
Bool
InvalidParameter
-
r
0x8442
Bool
Parameters cannot be changed in ON state
-
r
0x8443
Bool
Parameters disable CPU/master active
-
r
0x8444
Bool
No external start parameters received
-
r
low
0x8448
Bool
Self-test active
-
r
0x844A
Bool
Error during self-test
r
r
0x844B
Bool
Factory settings restored
r
r
0x8405
high
0x8450
Unsigned16
Parameter number error
3)
-
r
0x8406 high
0x8463
Bool
Preset unequal actual configuration
r
r
0x8465
Bool
Temperature sensor overload
-
r
0x8466
Bool
Temperature sensor wire break
-
r
0x8467
Bool
Temperature sensor short-circuit
-
r
low
0x8468
Bool
Parameter set 1 active
-
r
0x8469 Bool Parameter set 2 active - r
0x846A
Bool
Parameter set 3 active
-
r
0x846C
Bool
Parameter set change not possible
-
r
0x846E
Bool
Preset unequal actual configuration
-
r
0x846F
Bool
Type of motor connection wrong
-
r
0x8407 high
0x8472
Bool
Motor heating active
-
r
0x8473
Bool
DC braking active
-
r
0x8474
Bool
Dynamic DC braking active
-
r
0x8475
Bool
Type of motor connection star/delta
r
r
0x8476
Bool
Type of motor connection inside-delta
r
r
0x8477
Bool
Motor connection type unknown
r
r
low
0x8478
Bool
Load missing
r
r
0x847A
Bool
Phase failure L1
r
r
0x847B
Bool
Phase failure L2
r
r
0x847C
Bool
Phase failure L3
r
r
0x847D
Bool
Main power rotation right
r
r
0x847E
Bool
Main power rotation left
r
r
0x847F
Bool
Supply voltage too high
-
r
