Siemens SIRIUS 3RW5 series User Manual

Appendix
A.2 Data tables
SIRIUS 3RW5 Modbus TCP communication module
Manual, 03/2018, A5E43676481002A/RS-AA/001
97
Register
Byte
Data format
[Obj. No.]
Parameters
Range of values
[encoding]
Increment
3RW
Address
high / low
52
1)
[D*]
55
2)
[D*]
0x9449 high Unsigned32
[2224]
Analog output - range start
value
0 … 4 294 967 295
[0 … 4 294 967 295]
1 r
[0]
r/w
[0]
0x944B high Unsigned32
[2225]
Analog output - range end
value
0 … 4 294 967 295
[0 … 4 294 967 295]
1 r
[96]
r/w
[27 648]
0x944E high Bool
[34]
Response to CPU/Master
Stop
[0 ... 1] - - r/w
[0]
[0] Switch substitute
value
[1] Keep last value
0x944F high Bit32
[35]
Substitute value - - - r/w
[0]
0x9452 high Bit2
[140]
Response to overload
switching element
[0 ... 1]
- r
[0]
r/w
[0]
[0] Turn off without
restart
[1] Turn off with restart
0x9453 high Bit4
[232]
Response to faulty main
power
[1 ... 2]
- - r/w
[1]
[1] Group error only at
ON command
[2] Warn
0x9454 high Bit4
[129]
Response to preset unequal
actual configuration
[0 ... 4]
- - r/w
[0]
[0] Turn off
[1] Warn
[4] Ignore
0x9455 high Bit4
[2344]
Pump cleaning mode [0 ... 1] - - r/w
[0]
[0] Deactivated
[1] Manual
low Bit4
[2345]
Pump cleaning - start/stop
parameters
[1 ... 5]
- - r/w
[5]
[1] Parameter set 1
[2] Parameter set 2
[3] Parameter set 3
[5] Operating parameters
0x9456 high Unsigned8
[2346]
Pump cleaning - time 0 ... 30 s
[0 ... 30]
1 s - r/w
[20]
low Unsigned8
[2347]
Pump cleaning - cycles 0 ... 10
[0 ... 10]
1 - r/w
[3]
0x9457 high Unsigned16
[2352]
Current limiting value -
automatic parameterization
125 ... 800 %
[125 ... 800]
1 % - r/w
[400]
