Siemens SIRIUS System Manual

3RV1 circuit breaker
SIRIUS System Manual
GWA 4NEB 430 0999-02b
2-61
Permissible rating of approved devices for North America,
u s
The circuit breakers in the SIRIUS 3RV1 series are approved for
u
/
s
and can also be used in acc. with UL 508 and C22.2 No.14 with a
contactor as a load feeder. You can use these circuit breakers as a "Manual Motor Starter" for "Group Fusing" or for "Group Installation" or as a
"Combination Motor Controller
Ty p e E
".
3RV1 circuit breaker as a "Manual Motor Starter"
When the circuit breaker is used as a "Manual Motor Starter", it is always with a device for short-circuit protection (upstream short-cir-
cuit protection device). Any fusible link ("group fusing") or circuit breaker ("group installation") can be used as a device for short-circuit
protection. The type and size are selected in acc. with the American NFPA 70 standard, Article 430-53 (c) for adequate protection of
supply lines.
Accreditation was issued under the following file numbers with the listed data:
u
File No. E14705, Product Class NLRV
s
File No. LR12730, Product Class 3211 05
Circuit breaker Hp rating Rated current
To 240 VAC To AC 480 Y/277 V To AC 600 Y/347 V
For FLA max.
I
n
I
cu
1
)
I
cu
1
)
I
cu
1
)
Type V 1-phase 3-phase A kA kA kA
0.11 to 2 50 50 10
3RV10 11
2.5 50 50 10
3RV16 11-0BD10
115 ½ - 3.2 50 50 10
200 1½ 3 4 50 50 10
Frame size S00
230 2 3 5 50 50 10
460 - 7½ 6.3 50 50 10
FLA max. 12 A, 600 V
575/600 - 10 8 50 50 10
NEMA Size 00
10 50 50 10
12 50 50 10
0.11 to 3.2 50 50 30
3RV10 21/3RV11 21
4505030
3RV13 21
5505030
115 2 - 6.3 50 50 30
Frame size S0 200 3 7½ 8 50 50 30
230 5 7½ 10 50 50 30
FLA max. 25 A, 600 V 460 - 15 12.5 50 50 30
NEMA Size 1 575/600 - 20 16 50 50 30
20 50 50 30
22 50 50 30
25 50 50 30
3RV10 31/3RV11 31
11 to 16 50 50 25
3RV13 31
20 50 50 25
115 3 - 25 50 50 25
Frame size S2 200 7½ 15 32 50 50 25
230 10 20 40 50 50 25
FLA max. 50 A, 600 V 460 - 40 45 50 50 25
NEMA Size 2 575/600 - 50 50 50 50 25
11 to 16 50 50 30
3RV10 41/3RV10 42
20 50 50 30
3RV11 42
115 10 - 25 50 50 30
3RV13 41/3RV13 42
200 20 30 32 50 50 30
230 20 40 40 50 50 30
Frame size S3 460 - 75 50 50 50 30
575/600 - 100 63 50 50 30
FLA max. 99 A, 600 V 75 50 50 30
NEMA Size 3 90 50 50 30
100 (99) 50 50 30
Hp rating = output power in horse power (maximum motor power)
FLA = full load amps
1) Corresponds to "short circuit breaking capacity" in acc. with UL
