Siemens SIRIUS System Manual

3RV1 circuit breaker
SIRIUS System Manual
2-62
GWA 4NEB 430 0999-02b
Permissible rating of approved devices for North America,
u s
3RV10.A circuit breaker as "Combination Motor Controller Type E"
Since 16.07.2001, 1 inch air clearance and 2 inch creepage distance is required for a "Combination Motor Controller Type E" on the input
side with UL 508 The 3RV10 circuit breaker in frame sizes S0 and S3 are therefore approved with the terminal blocks listed below in
acc. with UL 508.
The 3RV10 circuit breaker in frame size S2 already complies with the required air clearance and creepage distance as a basic unit.
These extended air clearances and creepage distances are not required for CSA. The terminal blocks are therefore not required for use
as a "Combination Motor Controller Type E" in acc. with CSA. 3RV10 circuit breakers are certified as "Combination Motor Controller
Ty p e E
" under the following file numbers with the listed data:
u
File No. E156943, Product Class NKJH
s
File No. LR12730, Product Class 3211 08
Hp rating = output power in horse power (maximum motor power)
FLA = full load amps
1) Corresponds to "short circuit breaking capacity" in acc. with UL
Circuit breaker Hp rating Rated current
To 240 VAC To AC 480 Y/277 V To AC 600 Y/347 V
For FLA max.
I
n
I
cu
1
)
I
cu
1
)
I
cu
1
)
Type V 1-phase 3-phase A kA kA kA
0.11 to 1.6 50 50 30
3RV10 21
2505030
+ 3RV19 28-1H
115 2 - 2.5 50 50 30
200 3 7½ 3.2 50 50 30
Frame size S0
230 3 7½ 4 50 50 30
460 - 15 5 50 50 30
FLA max. 22 A, 480 V
575/600 - 10 6.3 50 50 30
12.5 A, 600 V
8505030
NEMA Size 1 10 50 50 30
12.5 50 50 30
16 50 50 -
20 50 50 -
22 50 50 -
0.9 to 16 50 50 25
3RV10 31
20 50 50 25
115 3 - 25 50 50 25
Frame size S2 200 7½ 15 32 50 50 25
230 10 20 40 50 50 25
FLA max. 50 A, 600 V 460 - 40 45 50 50 25
NEMA Size 1 575/600 - 50 50 50 50 30
3RV10 31/3RV11 31
11 to 16 50 50 25
3RV13 31
20 50 50 25
115 3 - 25 50 50 25
Frame size S2 200 7½ 15 32 50 50 25
230 10 20 40 50 50 25
FLA max. 50 A, 600 V 460 - 40 45 50 50 25
575/600 - 50 50 50 50 25
NEMA Size 2
11 to 16 50 50 30
3RV10 41
20 50 50 30
+ 3RT19 46-4GA07
115 10 - 25 50 50 30
200 20 30 32 50 50 30
Frame size S3 230 20 40 40 50 50 30
460 - 75 50 50 50 30
FLA max. 100 A, 480 V 575/600 - 75 63 50 50 30
75 A, 600 V 75 50 50 30
90 50 50 -
NEMA Size 3 100 50 50 -
Rating of the control switches and alarm switches
Lateral
auxiliary switch with
1NO + 1NC, 2NO,
2NC, 2NO + 2NC
and alarm switch
Tr a n s v e r s e
auxiliary switch with
1 changeover contact
Transverse
auxiliary switch with
1 NO + 1 NC, 2 NO
Max. rated voltage
• In acc. with NEMA
u
VAC 600 240
• In acc. with NEMA
s
VAC 600 240
Continuous current A 10 5 2.5
Switching capacity A600 B600 C300
Q300 R300 R300

Siemens SIRIUS Specifications

General

Product brand name	Siemens
Series	SIRIUS
Coil Voltage	24V DC, 110V AC, 230V AC
Switching Capacity	Up to 10A
Mounting Type	DIN rail
Product designation	SIRIUS
Contact Material	Silver alloy
Contact Rating	Varies depending on the specific SIRIUS relay model (e.g., 6 A at 250 V AC, 10 A at 250 V AC)
Switching Voltage	Varies depending on the specific SIRIUS relay model (e.g., 250 V AC, 400 V AC)
Mechanical Life	Up to 10 million operations
Electrical Life	Up to 100, 000 operations
Operating Temperature	-25°C to +55°C
Protection Class	IP20
Size of relay base	Varies depending on the specific SIRIUS relay model
