3RT1/3RH1 contactors
SIRIUS System Manual
3-126
GWA 4NEB 430 0999-02b
3RT15 contactors, 4-pole (2 NO contacts + 2 NC main contacts)
1) Corresponds to section from IEC 60 947-4 (VDE 0660 Part 102):
Coordination type "1":
The destruction of the contactor and the overload relay is permissible. The contactor and/or overload relay must be replaced, if necessary.
Assignment "2":
The overload relay must not be damaged. Contactwelding on the contactor is permissible, if it can be easily separated again from the contactor.
2)Test conditions in acc. with IEC 60 947-4-1
Contactor Frame size
Type
S00
3RT15 16/17
S0
3RT15 26
S2
3RT15 35
General specifications
Mechanical life
Opera-
ting
cycles
30 mill. 10 mill. 10 mill.
Electrical service life with
I
e
/AC-1
Opera-
ting
cycles
Approx. 0.5 mill.
Rated insulation voltage
U
i
(pollution degree 3) V 690
Permissible ambient temperature
For operation
During storage
°C
°C
–25 to +60
–55 to +80
Degree of protection
in acc. with IEC 60 947-1 and DIN 40 050 IP20 IP 20
(terminal housing IP 00)
Short-circuit protection for contactors without overload relay
Main circuit
Fuse-links, performance class gL/gG
NH type 3NA,
DIAZED type 5SB,
NEOZED type 5SE
– In acc. with IEC 60 947-4/
DIN EN 60 947-4 (VDE 0660 Part 102)
Coordination type "1"
1
)
Coordination type "2"
1
)
Unwelded
2
)
A
A
A
35
20
10
63
35
16
160
80
50
Drive
Operating range of the magnet coils
AC
DC
at 50 Hz:
at 60 Hz:
at +50 °C
at +60 °C
0.8 to 1.1 x
U
s
0.85 to 1.1 x
U
s
0.8 to 1.1 x
U
s
0.85 to 1.1 x
U
s
AC/DC: 0.8 to 1.1 x
U
s
Power input of the magnet coils
(cold coil and at 1.1 x
U
s
)
AC operation Hz 50/60 50 50/60 50 50/60
Making capacity
cos
ϕ
VA 26.5/24.3
0.79/0.75
61 64/63
0.82 0.82/0.74
145 170/155
0.79 0.76/0.72
Holding power
cos
ϕ
VA 4.4/3.4
0.27/0.27
7.8 8.4/6.8
0.24 0.24/0.28
12.5 15/11.8
0.36 0.35/0.38
DC operation Making capacity = holding power W 3.3 5.6 13.3
