Communication
11.7 DR 4 Temporary parameters
SIWAREX WT241
116 Manual, 05/2015, A5E36046748A
Variable
Note
Type
L
Rw
Default
Min.
Max.
Register
Pulses per belt
revolution
Pulses for one belt revolution,
determination with empty belt
using "Start/Stop belt revolu-
tion detection" commands
Command for importing: "Ap-
ply pulse parameter" (87)
LONG
4
r
0
1212
Pulses per second
at nominal speed
(Vmax)
Determination using the
"Start/Stop belt revolution
detection" commands with
empty belt
Command for importing: "Ap-
ply pulse parameter" (87)
LONG
4
r
0
1214
Reserve
LONG
4
r
0
1216
Reserve
LONG
4
r
0
1218
Reserve
LONG
4
r
0
1220
Initial zero calibra-
tion digits
Measure mean value following
calibration command "Start
initial zero calibration".
Command for importing: "Ap-
ply initial zero calibration dig-
its" (88)
LONG
4
r
0
1222
Deviation from old
initial zero calibra-
tion digits (%)
Is calculated following deter-
mination of zero calibration
digits
FLOAT
4
r
0
1224
Calibration weight
(calculated)
Determine from the automatic
calibration or from the weight
calibration or from the load
calibration or from the amount
of material
Command for importing: "Ap-
ply span calibration digits" (89)
FLOAT
4
r
0
1226
Calibration load
(calculated)
Measure mean value
FLOAT
4
r
0
1228
Span calibration
digits
Measure mean value following
calibration commands
LONG
4
r
0
1230
Deviation from old
span calibration
digits (%)
Is calculated following deter-
mination of span calibration
digits
FLOAT
4
r
0
1232
Nominal belt load
(calculated)
Design flow rate / design
speed
FLOAT
4
r
0
1234
Deviation from old
nominal belt load
(%)
Is calculated from the nominal
power, nominal speed, and
weigh length.
FLOAT
4
r
0
1236
Stop watch
(Page 117)
Start/Stop via command or
with zeroing or calibration
commands
LONG
4
r
0
1238
