11.7 DR 4 Temporary parameters
SIWAREX WT241
Manual, 05/2015, A5E36046748Aa 115
11.7 DR 4 Temporary parameters
Data record DR 4 temporarily displays the results of the calibration commands. You can
decide if you wish to apply the results and transfer them to the parameter set in DR 3. The
new calibration results become effective following importing into the parameter set. The
temporary parameters are not saved powerfail-proof.
This data record cannot be sent to the scale.
Table 11- 5 Assignment of data record 4
Variable
Note
Type
L
Rw
Default
Min.
Max.
Register
Data record num-
ber
Contains no. of data record
USHORT
2
r
4
-
-
1200
Length
Data record length information
USHORT
2
r
88
-
-
1201
Application
Information about which appli-
cation the DR belongs to
USHORT
2
r
104
-
-
1202
Version identifier
Information about current data
record version
USHORT
2
r
1
1
65635
1203
Vmax. Speed (belt
empty)
Determination using the
"Start/Stop belt revolution
detection" commands with
empty belt
Command for importing: "Ap-
ply (nominal) speed" (85)
FLOAT
4
r
0
1204
Speed correction if
belt loaded
Only relevant if a sensor is not
present, determination using
the "Start/Stop belt revolution
detection" commands with
empty belt
Command for importing: "Ap-
ply speed parameters "belt
loaded"" (86)
FLOAT
4
r
0
1206
Belt load factor for
the speed correc-
tion
Only relevant if a sensor is not
present, determination using
the "Start/Stop belt revolution
detection" commands with
empty belt
Command for importing: "Ap-
ply speed parameters "belt
loaded"" (86)
FLOAT
4
r
0
1208
Impulse constant
speed sensor
Impulses per length unit
(length unit from belt load),
Determination using the
"Start/Stop belt revolution
detection" commands with
empty belt
Command for importing: "Ap-
ply pulse parameter" (87)
LONG
4
r
0
1210
