SIWAREX WT241
Manual, 05/2015, A5E36046748A 181
SIWAREX WP241 manual
in various languages
Free download from the Internet WP241 manuals
(http://support.automation.siemens.com/WW/view
/de/64722267/133300)
Ethernet patch cable CAT5
To connect the SIWAREX to a PC (SIWATOOL),
SIMATIC CPU, panel, etc.
SIWAREX JB junction box
For parallel connection of load cells
SIWAREX EB extension box
For extending load cell cables
Ex interface, type SIWAREX IS
With ATEX approval for intrinsically-safe connec-
tion of load cells, including manual, suitable for
the load cell groups SIWAREX CS, U, M, FTA, P,
WP231, WP321, and WP241
With short-circuit current < 199 mA DC
With short-circuit current < 137 mA DC
Cable Li2Y 1 x 2 x 0.75 ST + 2 x (2 x 0.34 ST) -
CY
To connect SIWAREX CS, U, M, P, A,
WP231, WP321, and WP241 to the junction
box (JB), extension box (EB) or Ex interface
(Ex-I) or between two JBs, for fixed laying
Occasional bending is possible
10.8 mm outer diameter
For ambient temperature -20 to +70 °C
