11.27 DR 34 ASCII main display value
SIWAREX WT241
166 Manual, 05/2015, A5E36046748A
11.27 DR 34 ASCII main display value
The ASCII display value corresponds to the value on the scale's main display. The content
can be controlled using display commands.
Table 11- 27 Assignment of data record 34
Variable
Note
Type
L
Rw
Default
Min.
Max.
Register
Data record
number
Contains no. of data record
USHORT
2
r
34
-
-
4000
Length
Data record length information
USHORT
2
r
26
-
-
4001
Application
Information about which appli-
cation the DR belongs to
USHORT
2
r
104
-
-
4002
Version
identifier
Information about current data
record version
USHORT
2
r
1
1
65635
4003
ASCII dis-
play string
header
Maximum length and actual
length of string
UBYTE[2]
2
r
16.2
-
-
4004
Content of
main display
as ASCII
string
(Page 166)
For display of the material flow
rate, belt load, speed, totals
CHAR[16]
16
r
" "
-
-
4005
11.27.1 Content of main display as ASCII string
Commands are used to toggle the display.
The following values can be displayed in belt scale applications:
Value
Command
Material flow rate
710
Weight
715
Flow rate in %
735
Belt load
740
Belt load in %
745
Speed
760
Speed in %
765
Accumulated total
771
Main total
772
Totalizer S3
773
Totalizer S4
774
Totalizer S5
775
Totalizer S6
776
Official calibration
801
