Communication
11.13 DR 10 load cell parameters
SIWAREX WT241
Manual, 05/2015, A5E36046748Aa 135
11.13 DR 10 load cell parameters
The parameters of the analog load cells must be checked prior to the automatic calibration
and modified if necessary. Only the parameters identified by bold font and asterisk (*) need
be entered.
Procedure
● Check the parameters and modify them as required
● Transfer the data record to the scale
● Calibrate the scale
Table 11- 13 Assignment of data record 10
Variable
Note
Type
L
Rw
De-
fault
Min.
Max.
Register
Data record
number
Contains no. of data record
USHORT
2
r
10
-
-
1400
Length
Data record length information
USHORT
2
r
38
-
-
1401
Application
Information about which appli-
cation the DR belongs to
USHORT
2
r
104
-
-
1402
Version iden-
tifier
Information about current data
record version
USHORT
2
r
1
1
65635
1403
Number of
load cells
(Page 135)
1)
Number of analog load cells
USHORT
2
rw
1
1
6
1404
50/60 Hz
toggling
(Page 136)
50/60 Hz toggling
USHORT
2
rw
0
0
1
1405
Reserve 1
Reserve
USHORT
2
rw
0
0
0
1406
Load cell
characteristic
value
(Page 136)
1)
Characteristic value of the
load cell (n) [mV/V], the mean
value is used if there is more
than one cell.
FLOAT
4
rw
2
> 0.1
10
1407
Rated load of
a load cell
(Page 136)
1)
Rated load of a load cell
FLOAT
4
rw
60
-
-
1409
Reserve
Reserve
FLOAT
4
rw
0
-
-
1411
Reserve
Reserve
FLOAT
4
rw
0
-
-
1413
Reserve 2
Reserve
SHORT
2
rw
0
-
-
1415
Reserve 3
Reserve
USHORT
2
rw
0
-
-
1416
Reserve 4
Reserve
FLOAT
4
rw
0
-
-
1417
1)
Parameter for calculation of calibration points with theoretical calibration
11.13.1 Number of load cells
The number of load cells is required for automatic calibration.
