11.9 DR 6 Limits
SIWAREX WT241
120 Manual, 05/2015, A5E36046748A
11.9 DR 6 Limits
Various limits are parameterized in data record DR 6. The factory-set parameters
correspond to the typical settings.
Procedure
● Read the current parameters from the SIWAREX module (receive)
● Check all parameters and modify them as required
● Transfer the data record to the SIWAREX module (send)
Table 11- 7 Assignment of data record 6
Variable
Note
Type
L
Rw
De-
fault
Min.
Max.
Register
Data record
number
Contains no. of data record
USHORT
2
r
6
-
-
1264
Length
Data record length information
USHORT
2
r
90
-
-
1265
Application
Information about which application the
DR belongs to
USHORT
2
r
104
-
-
1266
Version
identifier
Information about current data record
version
USHORT
2
r
1
1
65635
1267
Negative
and positive
zero offset
in %
(Page 122)
Negative range of zero adjuster referred
to the originally calibrated zero point.
Specification in % of maximum belt load
FLOAT
4
rw
1
0
100
1268
Positive range of zero adjuster referred
to the originally calibrated zero point.
Specification in % of maximum belt load
FLOAT
4
rw
3
0
100
1270
Smallest
totalized
value
(Page 122)
Smallest totalized value which may be
recorded with verification capability
FLOAT
4
rw
0
0
1272
Minimum
flow rate
(Page 122)
Min. flow rate in % of design flow rate
(for status display)
FLOAT
4
rw
0
0
200
1274
Maximum
flow rate
(Page 122)
Max. flow rate in % of design flow rate
(for status display)
FLOAT
4
rw
100
0
200
1276
Delay for
flow rate
limits
(Page 122)
Delay for output of status display for
flow rate (in ms)
LONG
4
rw
1
0
1278
Minimum
belt speed
(Page 122)
Min. belt speed for status display 'Mini-
mum belt speed violated' in % of design
speed
FLOAT
4
rw
10
0
100
1280
Maximum
belt speed
(Page 122)
Max. belt speed for status display 'Max-
imum belt speed violated' in % of design
speed
FLOAT
4
rw
100
0
200
1282
