Communication
11.9 DR 6 Limits
SIWAREX WT241
Manual, 05/2015, A5E36046748Aa 121
Variable
Note
Type
L
Rw
De-
fault
Min.
Max.
Register
Delay for
belt speed
limits
(Page 123)
Delay for output of status display for
belt speed (in ms)
LONG
4
rw
1
0
1284
Minimum
belt load
(Page 123)
Min. belt load for status display 'Mini-
mum belt load violated' in % of nominal
belt load
FLOAT
4
rw
5
0
100
1286
Maximum
belt load
(Page 123)
Max. belt load for status display 'Maxi-
mum belt load violated' in % of nominal
belt load
FLOAT
4
rw
100
0
200
1288
Delay for
belt load
limits
(Page 123)
Delay for output of status display for
belt load (in ms)
LONG
4
rw
1
0
1290
Reserve
LONG
4
rw
1
0
1292
Medium
load for
totalizing
(Page 123)
Min. belt load required to start totalizing.
Specification in % of nominal belt load
FLOAT
Reserve
4
rw
0
0
Frequency
low pass
filter
weight/belt
load/belt
speed
(Page 124)
Low-pass filter - filtering of weight limit
frequency
0: filter switched off
Range fg: 0.05 … 50 Hz
FLOAT
4
rw
0.5
0
50
1298
Order no
low pass
filter
(Page 124)
Filter number 2*(1…5)
USHORT
2
rw
4
1
5
1300
Reserve 2
Reserve
FLOAT
4
rw
0
0
1301
Frequency
low pass
filter
weight/belt
load/belt
speed
(Page 124)
Low-pass filter - filtering of speed limit
frequency
0: filter switched off
fg: 0.05 … 50 Hz
FLOAT
4
rw
0
0
50
1302
Order no
low pass
filter
(Page 124)
Filter number 2*(1…5)
SHORT
2
rw
4
1
5
1304
Reserve
FLOAT
4
rw
0
0
0
1305
Reserve
USHORT
2
rw
0
0
0
1307
Depth av-
erage filter
flow rate
(Page 124)
Depth of average filter for weight meas-
urement (n x 10 ms)
USHORT
2
rw
0
0
0
1308
