8.16 Menu 5.0 User management
SIWAREX WT241
Manual, 05/2015, A5E36046748A 79
8.16 Menu 5.0 User management
The SIWAREX WT241 provides password protection. It is activated by default. The
password protection can be deactivated (and reactivated again) via a DIP switch at the
weighing module SIWAREX WP241 inside the terminal.
In case the password protection is activated, menu 5.0 “User management” will be available.
The menus 1.0 “Setup”, 3.0 “Language, Date & Time” and 5.0 “User management” are
protected by the password.
The default login values are:
User: ADMIN
Password: WT241
Activate and deactivate the passwort protection by DIP switch
Two DIP switches are located at the bottom side of the weighing module SIWAREX WP241
just next to the Ethernet port (accessible via the air inlet).
Figure 8-4 DIP switches at SIWAREX WP241weighing module
Position of
DIP switch
①password protection
②operation mode
Top
Password protection deactivated
Operating in SIMATIC
Bottom
Password protection activated
Operating stand alone
As default, both switches are located in the lower position, so that the password protection is
activated and the weighing module is in stand-alone operation mode.
For deactivating the password protection change the position of the left DIP switch ① to top.
It is important to keep the position of the right switch ② on bottom!
CAUTION
Take care to keep the login data (username, password) safe. Without password there is
not possibility to change settings or recalibrate the scale etc. In case no login data is
available anymore, you need to reinstall the user interface with an external software.
