Communication
11.10 DR 7 Process interfaces
SIWAREX WT241
126 Manual, 05/2015, A5E36046748A
Variable
Note
Type
L
Rw
Default
Min.
Max.
Register
Assignment of digital output .1
(see output .0)
USHORT
2
rw
0
0
0xFFFF
1319
Assignment of digital output .2
(see output .0)
USHORT
2
rw
0
0
0xFFFF
1320
Assignment of digital output .3
(see output .0)
USHORT
2
rw
0
0
0xFFFF
1321
Response
of digital
outputs to
faults or
SIMATIC
STOP
(Page 129)
Response of digital outputs following
module fault or CPU STOP:
0: Outputs are switched off
1: Outputs are not switched off, continue
2: The relevant substitute value is acti-
vated
3: The outputs are switched on
USHORT
2
rw
0
0
0
1322
Substitute
value for
DQ 0, 1, 2,
3 following
fault or
SIMATIC
STOP
(Page 129)
Substitute value for DQ.0 following fault
or SIMATIC CPU STOP
BIT
0
rw
0
0
1
1323.16
Substitute value for DQ.1 following fault
or SIMATIC CPU STOP
BIT
0
rw
0
0
1
1323.15
Substitute value for DQ.2 following fault
or SIMATIC CPU STOP
BIT
0
rw
0
0
1
1323.14
Substitute value for DQ.3 following fault
or SIMATIC CPU STOP
BIT
0
rw
0
0
1
1323.13
Bit 4
Reserve
BIT
0
rw
0
0
1
1323.12
Bit 5
Reserve
BIT
0
rw
0
0
1
1323.11
Bit 6
Reserve
BIT
0
rw
0
0
1
1323.10
Bit 7
Reserve
BIT
0
rw
0
0
1
1323.9
Bit 8
Reserve
BIT
0
rw
0
0
1
1323.8
Bit 9
Reserve
BIT
0
rw
0
0
1
1323.7
Bit 10
Reserve
BIT
0
rw
0
0
1
1323.6
Bit 11
Reserve
BIT
0
rw
0
0
1
1323.5
Bit 12
Reserve
BIT
0
rw
0
0
1
1323.4
Bit 13
Reserve
BIT
0
rw
0
0
1
1323.3
Bit 14
Reserve
BIT
0
rw
0
0
1
1323.2
Bit 15
Reserve
BIT
2
rw
0
0
1
1323.1
Analog
output
range
(Page 130)
0: 0 … 20 mA
1: 4 … 20 mA
USHORT
2
rw
0
0
1
1324
Analog
output
source
(Page 130)
Basis of analog value output:
0 = belt speed
1 = belt load
2 = material flow rate
3 = ext. specification DS17
4 = ext. specification S7 interface
USHORT
2
rw
2
0
3
1325
