Siemens XC10 Series - Page 23

Installation
23
Building Technologies A6V10257473_b_en_--.doc
Fire Safety & Security Products 01.2010
ON
1 2
1 4
ON
1 2
23 3 (insert in slot 4)
1 12 V – 12 Ah batteries
2 12 V – 17 Ah batteries
3 FCA1014 battery holder (option)
4 Slot for battery holder
Fig. 8 XC1005-A, battery installation
