SIGLENT
2 SDS1000CML/CNL/DL Service Manual
Waveform Intensity and Grid Brightness can be adjusted.
Menu display in the form of pop-up that in order to convenience users to
use it.
Multiple Language User Interface.
Support Multilingual online help system.
Standard interface: USB Host, USB Device, RS-232, Pass/Fail Out.
Specifications
These specifications apply to SDS1000CML/CNL/DL series Digital Storage
Oscilloscopes. To verify that an oscilloscope meets specifications, it must first
meet the following conditions:
The oscilloscope must have been operating continuously for thirty minutes
within the specified operating temperature.
You must perform the Do Self Cal operation, accessible through the Utility
menu, if the operating temperature changes by more than 5 °C.
The oscilloscope must be within the factory calibration interval of one year.
All specifications are guaranteed unless noted “typical”.
Table 1-2 Oscilloscope specifications
Inputs
Input Coupling AC, DC, GND
Input Impedance
（1MΩ±2%）||（16Pf±3Pf）
Maximum input voltage 400Vpk, CAT I I
Probe attenuation 1X, 10X
Probe attenuation ratio 1X, 5X, 10X, 50X, 100X, 500X, 1000X
Vertical System
Volts/Div Range 2mV/div~10V/div( in 1, 2, 5 sequence)
Channel Voltage
Offset Range
2mV~200mV: ±1.6V
206 mV~10V: ±40V
Vertical Resolution 8 bit
The number of channel 2
25M (SDS1022DL)
50M (SDS1052DL)
70M (SDS1072CML, SDS1072CNL)
100M (SDS1102CML, SDS1102CNL,
SDS1102DL)
150M (SDS1152CML)
Analog Bandwidth
200M (SDS1202DL)
To Next Page
