SDS1000CML/CNL/DL Service Manual 5
Table 1-3 Oscilloscope general specifications
Display System
Display Type Color TFT 7in.(178mm) Liquid Crystal Display
Resolution 480 horizontal by 234 vertical pixels
Display Color 24 bit
Display Contrast
（Typical state）
150:1
Backlight Intensity
（Typical state）
300nit
Wave display range 8 x 18 div
Wave Display Mode Dot, Vector
Persist Off, 1 sec, 2 sec, 5 sec, Infinite
Menu Display 2 sec, 5 sec, 10 sec, 20 sec, Infinite
Screen-Saver Off, 1min, 2min, 5min, 10min, 15min, 30min,
1hour, 2hour, 5hour
Skin Classical, Modern, Tradition, Succinct
Waveform
Interpolation
Sin(x)/x
Screen Display Normal , Invert
Language Simplified Chinese, Traditional Chinese, English,
Arabic, French, German, Russian, Portuguese,
Japanese, Korean, Italian
Power Supply
Input Voltage 100~240 VAC, CAT II, Auto selection
Frequency Scope 45Hz to 440Hz
Power < 50VA
Environments
Temperature
Operating:10℃ to +40℃
Not operating: -20℃ to +60℃
Cooling The fan forces it cold.
Humidity
Operating: 85%RH, 40℃, 24 hours
Not operating: 85%RH, 65℃, 24 hours
Height Operating: 3000m
Not operating: 15,266m
Mechanical
length 323.1mm
Width 135.6mm
Dimension
Height 157mm
Weight 2.5kg
