SIGLENT SDS1102CML - Function Checking Procedure

SIGLENT
8 SDS1000CML/CNL/DL Service Manual
Counter On
Pass/Fail Off
UTILITY
Record Off
TRIGGER Type Edge
Source CH1
Slope Rising
Mode Auto
Coupling DC
Edge TRIGGER
Level 0V
Source CH1
Condition = at positive pulse
Set Width 1.00ms
Mode Auto
Pulse TRIGGER
Coupling DC
Source CH1
Polarity Negative
Sync All lines
Standard NTSC
Video TRIGGER
Mode Auto
Source CH1
Condition > at Rising slope
Time 1.00ms
Mode Auto
Slope TRIGGER
Vertical The higher level
Source CH1
Mode Edge
Coupling DC
Alternative
Slope Rising
