22 SDS1000CML/CNL/DL Service Manual
 200MHz if you are testing a SDS1202DL
Table 3-4 Bandwidth test data
Volts/Div Input frequency Vpp measured
10Hz 3.0v
100Hz
1KHz
10KHz
100KHz
1MHz
10MHz
20MHz
30MHz
…
500mv/div
bandwidth
10Hz 1.2v
100Hz
1KHz
10KHz
100KHz
1MHz
10MHz
20MHz
30MHz
…
200mv/div
bandwidth
7. Every time you set to a frequency, it is better for you to adjust the
Sec/Div to a proper value thus to display a perfect waveform.
8. The V
pp
measurement of the waveform will decrease as the input
frequency increases. Increasing the input frequency gradually until
the V
pp
measurement gets closest to 2.12v.
9. Disconnect the connection of channel 1.
10. Check channel 2 in the same way as step 1 to 9.
For test at 200mv/div, please perform the same operation as that at
500mv/div, except for the initial amplitude and amplitude at bandwidth
listed below.
Table 3-4 Amplitude at bandwidth
Volts/Div
Initial
amplitude
Amplitude
at bandwidth
Initial
frequency
500mv/div 3v
0.707×3v=2.12v
10 Hz
200mv/div 1.2v
0.707×1.2v=0.848v
10 Hz
