Silvus StreamCaster S4200 - Voltage Reporting; Table 25 Voltage Reporting Format

StreamCaster 4000 series MIMO Radio User Manual 9/2/20
10017C000 Silvus Technologies Confidential Page
139
9.3 Voltage Reporting
The type, length and value for temperature reporting are listed in the following table:
Report Type
Data Type
Data
4001
START REPORT
Indicates start of voltage monitoring
report
1
END REPORT
Indicates end of report
4003
REVISION_REPORT
Indicates revision of this report,
currently always “1.1”
4004
CUR_VOLTAGE_REPORT
Current voltage value as a floating point
string
4005
MIN_VOLTAGE_REPORT
Minimum voltage seen so far, as a
floating point string
4006
MAX_VOLTAGE_REPORT
Maximum voltage seen so far, as a
floating point string
4007
UNDERVOLTAGE_COUNT_R
EPORT
Number of times voltage dropped below
min threshold, as an integer string
4008
OVERVOLTAGE_COUNT_RE
PORT
Number of times vltage spiked above
max threshold, as an integer string.
Table 25 Voltage Reporting Format
