4.2.4 SC4200 Pinouts
SC4200 Power/Ethernet/Serial Connector Pinout
Enclosure PWR/COMM
(LF10WBRB-12PD)
Signal
Switchcraft Pinout
(EN3C2F16X)
1
5V OUT (For External GPS Puck)
NC
2
GND IN (External Power Option Only)
2
3
GND IN (External Power Option Only)
2
4
VCC IN (External Power Option Only)
1
5
VCC IN (External Power Option Only)
1
6
100-Base T ETH0 M2N (RX-)
NC
7
100-Base T ETH0 M2P (RX+)
NC
8
100-Base T ETH0 M1P (TX+)
NC
9
RS232_RXD
NC
10
RS232_TXD
NC
11
RS232_GND
NC
12
100-Base T ETH0 M1N (TX-)
NC
Table 14 SC4200 Primary Power/Ethernet/Serial Connector Pinout
SC4200 RS-232 and PS/2 (GPS) Pinout
RS-232
PS/2 (GPS)
Signal
Switchcraft Pinout
3
4
TxD
2
2
5
RxD
1
NC
NC
NC
4
NC
2
5V OUT
6
NC
NC
NC
5
5
1
Ground
3
Table 15 SC4200 Serial and GPS Pinout
