Silvus StreamCaster S4200 - Table 18 MCS Vs. Sensitivity Chart (5 Mhz Bandwidth)

StreamCaster 4000 series MIMO Radio User Manual 9/2/20
10017C000 Silvus Technologies Confidential Page
58
Modulation Modes and Receiver Sensitivity
• Note that listed sensitivity values were measured using a controlled and cabled setup. Actual
results may vary by +/- 2dB. Table assumes link distance of 5000m. 10ms, 20ms, and 40ms burst
time for 20, 10, and 5MHz bandwidth respectively. 1600 byte Fragmentation Threshold.
• * Modes supported under the AUTO MCS option.
• * Modes supported under the EXTENDED AUTO MCS option in addition to AUTO MCS modes.
• *Modes currently not supported
NSS
MCS
Coding Rate
PHY Throughput
(Mbps)
UDP User Throughput
(Mbps)
SC4400/3500/3800
Sensitivity
SC4200/3822
Sensitivity
1
0
BPSK 1/2
1.625
1.03
-102
-99
1
1
QPSK 1/2
3.25
2.06
-100
-97
1
2
QPSK 3/4
4.875
3.09
-97
-94
1
3
16-QAM 1/2
6.5
4.12
-95
-92
1
4
16-QAM 3/4
9.75
6.18
-92
-89
1
5
64 QAM 2/3
13
8.25
-87
-84
1
6
64 QAM 3/4
14.625
9.28
-85
-82
1
7
64 QAM 5/6
16.25
10.30
-80
-77
2
8
BPSK 1/2
3.25
2.06
-100
-97
2
9
QPSK 1/2
6.5
4.12
-97
-94
2
10
QPSK 3/4
9.75
6.18
-94
-91
2
11
16-QAM 1/2
13
8.25
-91
-89
2
12
16-QAM 3/4
19.5
12.38
-88
-85
2
13
64 QAM 2/3
26
16.21
-84
-81
2
14
64 QAM 3/4
29.25
17.62
-82
-79
2
15
64 QAM 5/6
32.5
18.94
-77
-74
Table 18 MCS vs. Sensitivity Chart (5MHz Bandwidth)*
