Simplex 4010 Applications Manual

2-4
Use the PC Programmer’s List Tab to add the following to List L7 (Control
Points Off on Reset). Members of this list automatically turn off when a System
Reset is performed.
• Standard (non-QuickAlert) Visible NACs.
• Class B QuickAlert NACs.
• The Class A QuickAlert NACs wired to the “NAC IN” input of the SCM.
Note: Assign the Class A QuickAlert Horn Control NAC to List L6, as
described in “Step 3. Add Appropriate NACs to List L6 (Off on Silence)”
above.
Adding each floor’s initiating devices to a separate user-defined list limits the
number of Custom Control equations that must be written to perform Selective
Signaling by Floor. To add these devices to a list, use the PC Programmer’s List
Tab, adding each floor’s initiating devices to one of the available user-defined
lists (L26 through L50).
This section describes programming the Selective Signaling by Floor application
using either standard NAC appliances or Class A/Class B QuickAlert NAC
applicances. Refer to the applicable section below for specific information.
Standard NAC Example. The following example, shown in Figure 2-2,
illustrates how to implement Selective Signaling by Floor using standard NAC
appliances.
• Equation 1. The input side of this equation monitors the FIRE DETECT
state of list L26, which is a user-defined list containing all initiating devices
for Floor 1.
The first output statement programs the floor’s audible NACs to emit a
temporal signal when any point within list L26 enters an ALARM
condition. Because the audible NACs were added to the Control Points –
Off on Silence list, they stop sounding when an Alarm Silence occurs.
The second output statement programs the floor’s visible NACs to activate
when any point within list L26 enters an ALARM condition. Because the
visible NACs were added to the Control Points – Off on Reset list (L7),
they stop flashing when a System Reset occurs.
• Equation 2. The input side of this equation monitors the FIRE DETECT
state of list L27, which is a user-defined list containing all initiating devices
for Floor 2.
The first output statement programs the floor’s audible NACs to emit a
temporal signal when any point within list L27 enters an ALARM
condition. Because the audible NACs were added to the Control Points –
Off on Silence list, they stop sounding when an Alarm Silence occurs.
The second output statement programs the floor’s visible NACs to activate
when any point within list L27 enters an ALARM condition. Because the
visible NACs were added to the Control Points – Off on Reset list (L7),
they stop flashing when a System Reset occurs.
Continued on next page
Selective Signaling by Floor, Continued
Step 4: Add Appropriate
NACs to List L7 (Off on Reset)
Step 5. Add Floor’s Initiating
Devices to a User-Defined List
Step 6. Add Custom Control
Equations
