Simplex 4010 Applications Manual

A-11
Used to define the operation of a duct detector for all possible circuit states.
Circuit Status LCD Text Status
Normal Normal
Limited Duct Detector Fire Alarm
Open Duct Detector Open Trouble
Short Duct Detector Fire Alarm
Defines the operation of a heat detector for all possible circuit states.
Circuit Status LCD Text Status
Normal Normal
Limited Heat Detector Fire Alarm
Open Heat Detector Open Trouble
Short Heat Detector Fire Alarm
Use for flame detectors.
Circuit Status LCD Text Status
Normal Normal
Limited Flame Detector Fire Alarm
Open Flame Detector Open Trouble
Short Flame Detector Fire Alarm
Use with manual pull stations.
Circuit Status LCD Text Status
Normal Normal
Limited Manual Pull Station Fire Alarm
Open Manual Pull Station Open Trouble
Short Manual Pull Station Fire Alarm
Use for 2- and 4-wire smoke detectors.
Circuit Status LCD Text Status
Normal Normal
Limited Smoke Detector Fire Alarm
Open Smoke Detector Open Trouble
Short Smoke Detector Fire Alarm
Continued on next page
Point Types, Continued
DUCT
HEAT
FLAME
PULL
SMOKE
Technical Manuals Online! - http://www.tech-man.com

Simplex 4010 Specifications

General

Display	LCD
Power Supply	120/240 VAC, 50/60 Hz
Manufacturer	Simplex
Model	4010
Battery Backup	24 VDC
NAC Outputs	4
Max Detectors	250
Max Modules	250
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	Up to 93% RH, non-condensing
