Simplex 4010 Applications Manual

A-14
Used to indicate abnormal sprinkler conditions, such as the opening of a PIV or
OS&Y tamper switch. This point type must be used with normally open
contacts only.
Circuit Status LCD Text
Status
Normal Normal
Limited Sprinkler Monitor Abnormal
Open Sprinkler Monitor Open Trouble
Short Sprinkler Monitor Abnormal
Combination Waterflow/Sprinkler Monitor (NO). Where permitted by the AHJ,
this circuit operates both waterflow monitors and PIV/OS&Y tampers on the
same circuit. All tamper switches (N.O. contacts) must be connected with a
current limiting resistor. Refer to the 4010 field wiring diagrams. A short
condition indicates waterflow alarms.
Circuit Status LCD Text
Status
Normal Normal
Limited Sprinkler Monitor Abnormal
Open Sprinkler Monitor Open Trouble
Short Sprinkler Monitor Waterflow Alarm
Suppression (Agent Discharge) Monitor.
Circuit Status LCD Text Status
Normal Normal
Limited Suppression Detector Fire Alarm
Open Suppression Detector Open Trouble
Short Suppression Detector Fire Alarm
Suppression Abort (supervised)
Circuit Status LCD Text Status
Normal Normal
Limited Suppression Abort Activated
Open Suppression Abort Open Trouble
Short Suppression Abort Short Trouble
Manual suppression agent discharge
Circuit Status LCD Text Status
Normal Normal
Limited Suppression Manual Dump Activated
Open Suppression Manual Dump Open Trouble
Short Suppression Manual Dump Short Trouble
Continued on next page
Point Types, Continued
SO
WSO
SUPDET
SUPABRT
SUPDUMP
