Simplex 4010 Applications Manual

A-8
Generic Alarm Signal – no default operation. Used for selective control
(Custom Control) of audible or visible notification appliances. Points assigned
with this point type operate on general alarm.
Circuit Status LCD Display
System Status
ON Signal Circuit ON
OFF Signal Circuit OFF
Signal Circuit CODING
Disable TBL Signal Circuit TROUBLE
OFF AUTO TBLE Signal Circuit TROUBLE
Alarm signal – On until Silence. Used for any signaling device (such as an
audible or visible notification appliance) that is required to be on until reset.
Points assigned with this type operate on general alarm (that is, when any point
within L1 General Alarm List goes into alarm). Points with this type turn OFF
when an Alarm Silence is performed.
Circuit Status LCD Display
System Status
Normal Signal Circuit ON
Normal Signal Circuit OFF
Signal Circuit CODING
Disable TBL Signal Circuit TROUBLE
OFF AUTO TBLE Signal Circuit TROUBLE
Suppression release (agent discharge) output.
Circuit Status LCD Display System Status
Normal Signal Circuit ON
Normal Signal Circuit OFF
Signal Circuit CODING
Disable TBL Signal Circuit TROUBLE
Sprinkler supervisory signal. Turns ON when any point in L3 Sprinkler
Supervisory Monitor Points activates. Turns OFF on ACK or when the
supervisory clears. Example: Have a relay and its point type is SUPV, used to
set off a bell when a tamper is triggered or a gate valve is opened.
Circuit Status LCD Display
System Status LED
Normal Signal Circuit ON
Normal Signal Circuit OFF
Signal Circuit CODING
Disable TBL Signal Circuit TROUBLE
Continued on next page
