Simplex 4010 Applications Manual

A-4
Some application-specific needs can also be met without Custom Control simply
by using the correct point types. A point’s type determines the following:
• The message displayed on the 4010’s LCD when changes occur to the state
of the point’s circuit.
• The way in which the system operates (for example, initiate an Alarm,
Trouble, or Supervisory action) when changes occur to the state of the
point’s circuit.
AHU off relay – dual relay control. This point type is used with applications
that use two auxiliary relays for AHU control – one relay for ON and one relay
for OFF. Use this point type for the OFF relay. Points assigned with this type
operate on general alarm (that is, when any point within L1 “General Alarm
List” goes into alarm). Point turns OFF on Reset.
Stagger Start functionality for air handler units is provided by the “Stagger
Start” system option.
See AHUO for the ON relay point type. If you have a single relay that performs
both ON and OFF functions, see AHUR.
Circuit Status LCD Display
System Status
ON AHU OFF Relay ON
OFF AHU OFF Relay OFF
AHU OFF Relay CODING
Disabled TBL AHU OFF Relay TROUBLE
OFF AUTO TBL AHU OFF Relay TROUBLE
AHU on relay – dual relay control. This point type is used with applications that
use two auxiliary relays for AHU control – one relay for ON and one relay for
OFF. Use this point type for the ON relay. Points assigned with this type
operate on general alarm (that is, when any point within L1 “General Alarm
List” goes into alarm). Point turns OFF on Reset.
Stagger Start functionality for air handler units is provided by the “Stagger
Start” system option.
See AHUF for the OFF relay point type. If you have a single relay that
performs both ON and OFF functions, see AHUR.
Circuit Status LCD Display
System Status
ON AHU ON Relay ON
OFF AHU ON Relay OFF
AHU ON Relay CODING
Disabled TBL AHU ON Relay TROUBLE
OFF AUTO TBL AHU ON Relay TROUBLE
Continued on next page
Point Types
Introduction
AHUF
AHUO
