Simplex 4010 Applications Manual

A-12
Use for an emergency monitor zone in which two types of alarm devices – for
example, emergency alarm devices such as Nurse Call and fire alarm devices --
are connected to an IAM or ZAM. Emergency devices require the use of a
current limiting resistor. These devices generate an Emergency Alarm condition
at the panel.
Circuit Status LCD Text
Status
Normal Normal
Limited Monitor Zone Emergency Alarm
Open Monitor Zone Open Trouble
Short Monitor Zone Fire Alarm
Used when smoke detectors and shorting type devices are connected to an IAM
or ZAM.
Circuit Status LCD Text
Status
Normal Normal
Limited Fire Monitor Zone Smoke Alarm
Open Fire Monitor Zone Open Trouble
Short Fire Monitor Zone Fire Alarm
Used to activate the alarm verification software for all smoke detectors
connected to an IAM or ZAM. Shorting type devices cause an immediate alarm.
Circuit Status LCD Text
Status
Normal Normal
Limited Fire Monitor Zone Verified Alarm
Open Fire Monitor Zone Open Trouble
Short Fire Monitor Zone Fire Alarm
Used when smoke detectors and pull stations are connected to an IAM or ZAM.
Circuit Status LCD Text Status
Normal Normal
Limited Fire Monitor Zone Smoke Alarm
Open Fire Monitor Zone Open Trouble
Short Fire Monitor Zone Manual Alarm
Used when smoke detectors that must be verified and pull stations are connected
to an IAM or ZAM.
Circuit Status LCD Text
Status
Normal Normal
Limited Fire Monitor Zone Verified Alarm
Open Fire Monitor Zone Open Trouble
Short Fire Monitor Zone Manual Alarm
Continued on next page
Point Types, Continued
EMERG
SFIRE
VFIRE
SPULL
VSPULL
