Simplex 4010 Applications Manual

3-1
This chapter describes the 4010 programming required for common
suppression-release applications.
Basic applications, which do not involve pre-signaling or an abort switch with
delay, can be programmed without Custom Control using a mix of the 4010’s
built-in system options, point types, and lists. More complex applications,
involving pre-signaling or an abort switch with delay, require Custom Control
programming.
Before continuing, make sure that you have the following information:
• Fire Alarm STRM Ref. number SEB-FAS0899-01. This STRM contains
critical information concerning UL, FM, and IRI suppression requirements.
• Field Wiring Diagram 842-058.
• Field Wiring Diagram 842-073.
• Detailed knowledge concerning AHJ requirements .
Refer to the following page for specific information on a topic.
Topic See Page #
Default Suppression Release Applications 3-2
Dual Detector, Pre-Signal, and Abort Switch with
No Delay
3-5
Dual Detector, Pre-Signal, and Abort Switch with
Delay
3-8
Chapter 3
Suppression Release
Overview
In this Chapter
Technical Manuals Online! - http://www.tech-man.com

Simplex 4010 Specifications

General

Display	LCD
Power Supply	120/240 VAC, 50/60 Hz
Manufacturer	Simplex
Model	4010
Battery Backup	24 VDC
NAC Outputs	4
Max Detectors	250
Max Modules	250
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	Up to 93% RH, non-condensing
