Simplex 4010 Applications Manual

A-13
Used when emergency generator monitoring is required. The shorted condition
of the circuit indicates an abnormal status and is indicated by the Supervisory
Service LED. The current limited condition of the circuit indicates that the
generator is running, and can be tracked with an LED (must be programmed). A
current limiting resistor must be installed for this to happen.
Circuit Status LCD Text
Status
Normal Normal
Limited Generator Monitor Running
Open Generator Monitor Open Trouble
Short Generator Monitor Abnormal
Same operation as the GENMON point type, but the generator running condition
automatically displays and requires operator acknowledgment.
Circuit Status LCD Text
Status
Normal Normal
Limited Generator Monitor Running
Open Generator Monitor Open Trouble
Short Generator Monitor Abnormal
Used to monitor fire pump conditions. The shorted condition indicates that the
fire pump is abnormal A current limited condition indicates that the fire pump is
running.
Circuit Status LCD Text
Status
Normal Normal
Limited Fire Pump Monitor Running
Open Fire Pump Monitor Open Trouble
Short Fire Pump Monitor Abnormal
Same as the FPUMP point type, except that the fire pump running condition
requires operator acknowledgement.
Circuit Status LCD Text
Status
Normal Normal
Limited Fire Pump Monitor Running
Open Fire Pump Monitor Open Trouble
Short Fire Pump Monitor Abnormal
Used for 2-stage alarms. The current limited operation of any device indicate a
Stage 1 Alarm. A short on the point’s circuit, such as a key switch operation,
causes a Stage 2 Alarm.
Circuit Status LCD Text
Status
Normal Normal
Limited 2 Stage Monitor Stage 1 Alarm
Open 2 Stage Monitor Open Trouble
Short 2 Stage Monitor Stage 2 Alarm
Continued on next page
Point Types, Continued
GENMON
SGENMON
FPUMP
SFPUMP
S2STAGE
Technical Manuals Online! - http://www.tech-man.com
