Simplex 4010 Applications Manual

A-15
Suppression agent pressure switch monitor.
Circuit Status LCD Text Status
Normal Normal
Limited Suppression Pressure Discharge
Open Suppression Pressure Open Trouble
Short Suppression Pressure Short Trouble
Used to monitor any supervisory type device where operator acknowledgment is
required.
Circuit Status LCD Text
Status
Normal Normal
Limited Supervisory Monitor Abnormal
Open Supervisory Monitor Open Trouble
Short Supervisory Monitor Abnormal
Used to monitor and supervise any condition; operator acknowledgment is not
required. No alarm is generated by this point type.
Circuit Status LCD Text
Status
Normal Normal
Limited Utility Monitor Abnormal
Open Utility Monitor Open Trouble
Short Utility Monitor Abnormal
Used for trouble monitoring only. No alarm is generated by this point type.
Circuit Status LCD Text Status
Normal Normal
Limited Trouble Monitor Abnormal
Open Trouble Monitor Open Trouble
Short Trouble Monitor Abnormal
Used with smoke detectors whose alarm status must be verified.
Circuit Status LCD Text Status
Normal Normal
Limited Smoke Detector Verified Alarm
Open Smoke Detector Open Trouble
Short Smoke Detector Fire Alarm
Continued on next page
Point Types, Continued
SUPPRES
SUPV
UTIL
TROUBLE
VSMOKE
Technical Manuals Online! - http://www.tech-man.com

Simplex 4010 Specifications

General

Display	LCD
Power Supply	120/240 VAC, 50/60 Hz
Manufacturer	Simplex
Model	4010
Battery Backup	24 VDC
NAC Outputs	4
Max Detectors	250
Max Modules	250
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	Up to 93% RH, non-condensing
