Door holder control (normally off). Used when the auxiliary relay is connected
to door holders. The relay energizes on alarm (any point in L1 General Alarm
List goes into alarm), loss of AC Power, or when programmed.
Circuit Status LCD Display
System Status
ON Door Holder ON
OFF Door Holder OFF
Door Holder CODING
Disable TBL Door Holder TROUBLE
OFF AUTO TBL Door Holder TROUBLE
Elevator capture – primary. Used for any relay connected to the elevator
controls to provide primary floor elevator recall. A relay assigned this point
type turns ON when any point in L4, Primary Elevator Recall, goes into alarm.
Relay turns Off on reset.
Circuit Status LCD Display
System Status
ON Pri Elevator Capture ON
OFF Pri Elevator Capture OFF
Pri Elevator Capture CODING
Disable TBL Pri Elevator Capture TROUBLE
OFF AUTO TBL Pri Elevator Capture TROUBLE
QuickAlert signal. QALERT device type has no automatic operation. All
operations for this type of device type must be programmed with Custom
Control.
SQALERT device type automatically turns on the designated circuit on alarm
detect (general alarm), issues the horn silence command upon Alarm Silence,
and turns off the circuit at the completion of System Reset. Any point
programmed with the SQALERT point type is not available for use in Custom
Control programming.
Generic relay – no default operation. Used for selective relay applications
(Custom Control) not defined by a specific point type. Point must be
programmed to turn ON and OFF.
Circuit Status LCD Display
System Status
ON Auxiliary Relay ON
OFF Auxiliary Relay OFF
Auxiliary Relay CODING
Disable TBL Auxiliary Relay TROUBLE
OFF AUTO TBL Auxiliary Relay TROUBLE
Continued on next page
Point Types, Continued
DHOLDER
PRIMARY
QALERT
SQALERT
RELAY
