Simplex 4010 Applications Manual

A-17
4009A Point Type.
Circuit Status LCD Text Status
Normal Normal
Limited 4009A Abnormal
Open 4009A Open Trouble
Short 4009A Abnormal
2-position switch, unsupervised. Used for a 2-position switch without an EOL
or current limited resistor.
Circuit Status LCD Text
Status
Normal OFF
Limited 2-Position Switch Invalid State TBL
Open 2-Position Switch ON
Disable TBL 2-Position Switch Disable TBL
2-position switch, supervised for opens. Requires an EOL resistor.
Circuit Status LCD Text Status
Normal OFF
Limited 2-Position Switch Invalid State TBL
Open 2-Position Switch Open CKT TBL
Short 2-Position Switch ON
Disable TBL 2-Position Switch Disable TBL
2-position switch, supervised for opens and shorts. Requires EOL and current
limited resistors.
Circuit Status LCD Text
Status
Normal OFF
Limited 2-Position Switch ON
Open 2-Position Switch Open CKT TBL
Short 2-Position Switch SHORT CKT TBL
Disable TBL 2-Position Switch Disable TBL
3-position (SPDT) switch, supervised for opens. Requires EOL and series
current limiting resistors (up leg).
Circuit Status LCD Text
Status
Normal CENTER
Limited 3-Position Switch UP
Open 3-Position Switch Open CKT TBL
Short 3-Position Switch DOWN
Disable TBL 3-Position Switch Disable TBL
Point Types, Continued
4009A
USWITCH
OSWITCH
SSWITCH
TSWITCH
