Simplex 4010 Applications Manual

A-10
Trouble / Supervisory “Bell Relay.” A relay with this point type turns ON when
any Trouble or Supervisory condition occurs. Relays with this point type turn
OFF when the condition is acknowledged or cleared.
Circuit Status LCD Display
System Status
ON ON
ON OFF
CODING
Disable TBL TROUBLE
Disable TBL TROUBLE
Alarm Relay ON until Reset. A relay with this point type turns ON when any
point in L1, General Alarm List, goes into alarm. These relays turn OFF on
System Reset.
Circuit Status LCD Display
System Status
ON ON
ON OFF
CODING
Disable TBL TROUBLE
Disable TBL TROUBLE
This is a generic fire alarm point type. A typical application for this point type
is a fire alarm zone containing more than one type of device. For example,
when a combination of smoke detectors, pull stations, waterflow monitors, and
heat detectors is connected to an IAM or ZAM, this point type allows alarms to
report as originating from a zone.
Circuit Status LCD Text
Status
Normal Normal
Limited Fire Monitor Zone Fire Alarm
Open Fire Monitor Zone Open Trouble
Short Fire Monitor Zone Fire Alarm
When an Alarm or Trouble condition occurs, press Enter to view specific
information for the Fire Monitor Zone
Used to define the operation of a waterflow monitor for all possible circuit
states.
Circuit Status LCD Text
Status
Normal Normal
Limited Waterflow Monitor Fire Alarm
Open Waterflow Monitor Open Trouble
Short Waterflow Monitor Fire Alarm
Continued on next page
Point Types, Continued
BRELAY
RRELAY
FIRE
WATER
