Simplex 4010 Applications Manual

A-16
Used when the abnormal condition of the circuit must be verified.
Circuit Status LCD Text Status
Normal Normal
Limited Fire Monitor Verified Alarm
Open Fire Monitor Open Trouble
Short Fire Monitor Fire Alarm
Supervisory Monitor – latch until reset. Used for generic supervisory alarm.
Circuit Status LCD Text Status
Normal Normal
Limited Supervisory Alarm Abnormal
Open Supervisory Alarm Open Trouble
Short Supervisory Alarm Abnormal
Style-C Fire Alarm Monitor. Used when only current limited devices are
connected to the zone. A short circuit is reported as a Trouble.
Circuit Status LCD Text
Status
Normal Normal
Limited Fire Monitor Zone Fire Alarm
Open Fire Monitor Zone Open Trouble
Short Fire Monitor Zone Short Trouble
Supervisory Duct Detector.
Circuit Status LCD Text Status
Normal Normal
Limited Flame Detector Abnormal
Open Flame Detector Open Trouble
Short Flame Detector Abnormal
Abort zone.
Circuit Status LCD Text Status
Normal Normal
Limited Fire Alarm Abort Abnormal
Open Fire Alarm Abort Open Trouble
Short Fire Alarm Abort Abnormal
Damper Monitor
Circuit Status LCD Text Status
Normal Normal
Limited Damper Monitor Abnormal
Open Damper Monitor Open Trouble
Short Damper Monitor Abnormal
Continued on next page
Point Types, Continued
GVMON
LATSUPV
STYLEC
SDUCT
ABORT
DAMPER
