Operation
20222121A 27
The backlight of the display and buttons may be
adjusted to 10 levels (10 = brightest). The setting is
stored when the system is turned off. Adjustment is
local to the control unit you adjust or synchronized with
other units in the Simrad Group (page 73).
NAV source
Select the source for NAV mode steering e.g. CP34.
NAV WIND
This setup will configure the active mode under the
NAV WIND button. The following alternatives are
available:
• NAV (Ref page 21)
• NoDrift (Ref. page 20)
Note ! WIND is not an applicable mode on boats with the Volvo IPS
installed.
Source Select
Provides you with automatic or manual selection of
interfaced data sources for heading (Compass),
Navigation, Position, Wind Angle, Wind Calculated,
Water speed, Water temperature, Distance log and
Depth.
Wind-C(alculated) is a common term for true wind and
wind direction.
Auto source update
Is used for automatic selection of the interfaced sources
or for automatically update of sources if the interfaced
units have been removed/added or switched on/off.
Select Auto source update by pressing the STBD 10
button. Make sure all interfaced units are powered on.
The autopilot will search for new connected sources, and
replace sources no longer available.
