Simrad AP16 Autopilot
68 20222121A
4.7 Parameters
To access the Parameters, press the STBY 10 button.
A boats steering parameters found by the Automatic tuning can
be looked at and if needed changed under this menu item. The
steering parameters can also be set manually instead of
performing an Automatic tuning. The parameters are divided
into two sets (page 17):
• HI value parameters for automatic steering at low speed.
• LO value param
eters for automatic steering at high speed.
Step through the menu items by pressing the STBD 1 or
PORT 1 buttons. Adjust the value by using the STBD 10 or
PORT 10 buttons.
Manual parameter adjust
Displayed
parameter
Default
Automatic
tuning
Manual
Use STBD 10 and
PORT 10 buttons
to adjust value
LOw
Decrease: Press
10
Increase: Press
10
Rudder LO 0.20
Cont.Rudder LO 1.00
Autotrim LO 40 sec.
1
1
HIgh
Rudder HI 0.30
Cont.Rudder HI 1.40
Use PORT 1 and
STBD 1 buttons to
step through
parameters
Autotrim HI 40 sec.
Note ! The values in the table are factory set (default) and listed for
information only. After having performed the Automatic tuning,
the values may differ from those listed in the table. See also
“Automatic Tuning” previously in this chapter.
