Technical specifications
20222121A 87
Instrument screen NMEA0183 messages and SimNet
MAIN (HDG+RUDDER) ROBNET2 PROPRIETARY, NMEA HDT
and HTG, SimNet
SPEED/DEPTH VHW + DBT/DPT, SimNet
APPARENT WIND MWV, SimNet
TRUE WIND/WIND DIRECT. MWV + VTG/RMC; SimNet
POSITION GGA/RMC, SimNet
NAV/TRACK DATA APB + VTG/RMC + GGA/RMC +
RMB/BWC, SimNet
LOG/SEA TEMPERATURE VLW + MTW, SimNet
Note ! Alternative messages are separated by slashes.
8.2 AP16 Control Unit
Dimensions:............................... See Figure 8-1
Weight: ...................................... 0,5 kg (1.1 lbs)
Power consumption ................... 3 W
Display:
Type:................................. Backlit LCD matrix display
Resolution:........................ 160 x 128 pixels
Colour:....................................... Black
Illumination: .............................. Adjustable in 10 steps
Environmental Protection:......... IP56 from front, IP43 from back.
Safe distance to compass:.......... 0.5 m (1.6 ft.)
Temperature:
Operating: ......................... 0 to +55 °C (+32 to +130 °F)
Storage:............................. –30 to +80 °C (–22 to +176 °F)
