Operation

20222121A 29

Wind Angle

Select the source for Wind Angle.

Wind Calculated

Select the source for Calculated Wind data. The autopilot

uses internal source irrespective of the selected source.

Water Speed

Select the source for water speed (normally the same as the

source providing Log data).

Water temperature

Select the source for water temperature (normally the same

as the source providing depth data).

DisLog

Select the Log source.

Depth

Select the source for depth data.

Instrument Select

Select the instrument page(s) to be available under the

INFO/SETUP button. Step through the list of instrument

pages by using the PORT 1 or STBD 1 button. Select the

wanted pages by filling the squares with the PORT 10 or

STBD 10 button.

Available instrument pages are: Depth/Speed, Wind App.,

Wind True, Wind Dir., Track data, Nav data, Position and

Temperature.
