Chart reading is now in
stand-by, and you may in-
sert/remove cartridges.
To open the drawer below
the keypad, press the eject
key next to the drawer.
Place the cartridge in tray
with face up and terminals
pointing towards the unit,
and push the drawer to
close it - make sure it
clicks in all the way (to
stay watertight).
#ONFIRMTHATYOUWISHTOLOADTHE#-!0CARTRIDGE
CHARTDATA
The CE32 MKII will now test the data on the cartridge
to see if its valid and free from faults, or it will test if
there is any data present at all.
F If a cartridge is defect, it must be removed before
you can exit the display.
When the ’Cartridge status’ display informs that the
cartridge is O.K., exit with [MENU]
In addition to the larger boundaries of the world chart
there will be separate boundary lines for the individual
charts stored on the same cartridge.
Other chart areas can quickly be reached by:
:OOMOUTUNTILDESIREDAREABECOMESVISIBLE
-OVECURSORTOAPPROXIMATEAREAANDZOOMIN
C-MAP cartridge:
Name: MAP CARTRIDGE N. B0114.00
Chart reading is now in stand-by.
Insert/remove cartridge, and press ENT.
Test: ENT Exit: MENU
ENT
MENU
ZOOM
-
OUT
ZOOM
+
IN
#HAPTER #%-+))#HARTANDPOSITIONMENUS
18
