steps (by pressing [ZOOM] i.e. showing depth lines and
buoys, or only depth lines.
. HIGH - all available data is displayed in all scales.
. MEDIUM - depth lines and buoys are displayed.
. LOW - only depth lines are shown.
The depth areas 1, 2 and 3 are identified by different
colors i.e. deep blue, medium blue and light blue -
where light blue is for deep water. Alternative colors
can be selected. In the black & white display, the areas
are identified by the density of grey dots i.e. the fewest
dots are for the deepest water.
-OVECURSORTOTHEDESIREDSETTING
4OGGLEBETWEEN/.AND/&&
Continue in this manner until you have turned those of
the settings off which you do not require to have
shown on the chart at the moment.
#ONFIRMENTRYANDRETURNTOCHARTDISPLAY
In this display you can adjust what type of information
you want shown on the screen.
This gives you the opportunity to have an uncluttered
screen to look at with no more information than what is
needed for the time being.
Position in chart display can be shown in LAT/LON,
Loran C or in decca lanes.
,OADDISPLAYFOR #HARTSETUP - see next page.
+/-
ENT
1,6MENU
#HARTSETUP
KEYSTOPRESS
#HAPTER #%-+))#HARTANDPOSITIONMENUS
20
