Simrad CE33 ChartSounder User Manual

Chapter 1-4 CE33 Introduction and safety summary
1.3.2 Chart and chart functions
CHART
Press the [CHART] key to call Chart 1 and toggle data field or
echosounder split screen on/off
- see chart examples in section 1.3.1.
C-MAP cartridges (standby)
Press [MENU], [1], [3] whenever inserting or removing a C-MAP card.
Select and adjust chart or echosounder range
Press one of the numeric keys 1 - 9 to select a range (and chart level).
Key 9 will select the largest range and key 1 the smallest. Use the +/- keys to
adjust range in smaller steps.
Cursor and info windows
Press the cursor key to activate the cross hair cursor on the chart. Place the
cursor on a C-MAP object e.g. a buoy or light to call up a small data window
with details on the object. The data window will stay on screen for about 10
seconds or till cursor is moved. Press [ENT], [2] to access further details on
C-MAP objects or user data i.e. waypoints, routes, etc.
Press [CLR] to switch off cursor function. The ship symbol will now automat-
ically ‘home’ and stay on screen.
Find nearest tide station and port services
1. Press cursor key (to activate)
2. Press [ENT], [3]
3. Move cursor up/down to select e.g. the Port/Marina symbol
4. Locate alternative port with the +/- keys, and press [ENT]
5. Press [ENT], [2] for more details on the facilities at the selected port.
Navigate to cursor (point and go)
1. Move the cursor to where you wish to go (first point)
2. Press [GOTO]
3. Press [1] to start navigation.
You can now move the cursor to the next point and when ready to change leg,
just press [GOTO], [2].

Simrad CE33 ChartSounder Specifications

General

Brand	Simrad
Model	CE33 ChartSounder
Category	Marine GPS System
Language	English
