CE33 Fundamentals & initial start-up Chapter 2-3
2.2 Key functions
Some of the key functions are general and can be applied at any
time, other key functions are related to a certain menu(s) and can
only be applied when in the appropriate menu.
CHART
Hotkey to Chart 1 display. Toggles between chart display and split
screen with chart and data. Hold for 2 seconds to change to Chart 2.
ECHO
Hotkey to Echo display. Toggles A-scope on/off. Hold for 2 seconds
to change transmitter frequency 50/200 kHz.
PILOT
Hotkey to Highway display. Toggles between Highway, ETA &
AVN, Trim & highway displays.
PAGE
Toggles between four pre-selected pages (screens). Hold 2 seconds
for automatic rotation of the four pre-selected pages. A new, single
press will resume normal operation. Toggles through multi-screen
data displays.
MENU
Turns the menu bar on/off. Exits any data display without taking any
action.
ENT
Opens for/confirms insertion and editing of data. Calls up informa-
tion on marks, waypoints, etc. on chart together with several INFO
windows from a chart display. Gives access to setup displays.
Moves cursor in data displays and charts + activates cursor on chart.
Moves left/right/up/down in the menu system. Adjusts gain (left/
right) and moves VRM (up/down) in echo display.
MOB
Hold 2 seconds to activate the MOB - “Man overboard” function,
which starts a track and provides guidance back to the MOB posi-
tion.
GOTO
Activates INFO window with choice of navigation modes.
PLOT
From chart display: activates INFO window with the possibility of
plotting/inserting a waypoint, route, line etc., or the ship’s position
from any display.
+/-
+ (plus) zooms out for better overview (larger range) / - (minus)
zooms in for greater chart details (smaller range).
+ and - also toggles between available values.
