Chapter 2-8 CE33 Fundamentals & initial start-up
correct position without further data entries. The start-up phase is
completed when a position appears in the position display - see sec-
tion 4.1.
The echosounder function has a demo program, which can be acti-
vated in the Echosounder setup display, refer to section 7.8.
When a transducer has been installed and selected, and the
Echosounder function is set up and ready to perform, please make
sure that the demo mode is switched OFF.
Select display language:
MENU
Call up the menu bar, and...
7,1
press [7], [1] to call up the language display
Press up on the cursor to go to the bottom line in the display
+/-
Select language
ENT
Confirm entry
2.8 Turn power off
PWR
Call up INFO window, and...
PWR
Press and hold until screen turns black
The CE33 is now turned off. All the data and setups are saved and
stored in the internal memory and, of course, will be available next
time the unit is turned on.
