CE33 Introduction and safety summary Chapter 1-7
Advance or stop navigation
• Press [GOTO], [1] to advance to next point in the route.
• Press [GOTO], [3] to stop navigation.
Start and stop track
1. Press [MENU], [3], [5].
2. Before tracking is started, you can give the track a new name, make
changes to track interval, track line type and color.
3. Press [ENT] to start track.
4. When you wish to stop tracking, press [MENU], [3], [6], [ENT].
1.3.3 Echosounder / Fishfinder
ECHO
Press the [ECHO] key to call the echosounder display
- see display examples in section 1.3.1.
A-scope - Press the [ECHO] key to toggle A-scope on/off. The strength of the
actual echo is indicated by both width and color intensity.
Change frequency - Press and hold the [ECHO] key for two seconds to toggle
between 50 and 200 kHz.
Gain - Adjust gain with cursor left/right to just below the point where you
begin to see speckles of ‘noise’ on the screen.
Range - Select range by the numeric keys 1-9, or adjust with the +/- keys. Key
0 will select Auto Range.
Echo setup (presentation) - Press [ENT] from echo display to access the setup
display for either 50 or 200 kHz. Press [ENT] to confirm changes, or leave the
setup without having made any changes by pressing [MENU].
Bottom expansion* - Press [MENU], [5], [3] to expand the view of the
bottom in the echosounder display.
VRM expansion* - Press [MENU], [5], [4] to expand the view near the VRM
in the echosounder display. Use the up/down cursor to move the VRM marker.
*Return to standard echosounder display by pressing [MENU], [5], [3] or [4].
