Chapter 2-2 CE33 Fundamentals & initial start-up
Toggle between the four pre-set pages manually:
PAGE
Press the [PAGE] key - again and again - to toggle between the 4
pre-set pages, which as default are: Chart 1 with info field, Position,
Highway, Echo 200kHz displays.
The pre-set pages can also be toggled from an external switch - refer
to section 10.7 Optional connections.
Toggle between the four pre-set pages automatically:
PAGE
Hold the [PAGE] key depressed for two seconds to start a rotation of
the 4 pages in intervals of 5 seconds - this interval can be changed,
refer to section 9.1. Press [PAGE] again to return to normal opera-
tion.
Example of how to change a pre-set page:
For instance, if you are in the process of making a track, you may
want to exchange the Highway display with the Tracking display.
PAGE
Press the [PAGE] key until the Highway display appears
MENU
Call up the menu bar, and...
3,7
then call up the Tracking display
The same display can be selected for view in more than one page
if it is selected via the menu. The hotkeys: [CHART], [ECHO] and
[PILOT] will jump to the page with the desired display - if it’s there,
and if it’s not: it will be exchanged with the display in the active
page.
