MOB ‘MAN OVERBOARD’ function
MOB
In case someone falls overboard, press the [MOB] key and hold for 2
seconds (or activate an external MOB switch - hold for 5 seconds).
CLR
Press [CLR] to confirm and reset the alarm if activated by mistake.
ENT
Press [ENT] to make all relevant data available for an efficient
rescue operation:
MOB Page 1: The Chart 1 display will provide a graphical impres-
sion of a man
floating in the water at the MOB position together
with a course line from actual position to the incident.
The data field (if activated) will provide information of: current
speed, course, bearing, distance to MOB position, and current depth.
PAGE
MOB Page 2: The Chart 2 display will appear with the same type of
information as MOB Page 1.
PAGE
MOB Page 3: Data display will provide information of: Course,
Bearing and Distance to MOB position, time elapsed since the
incident occured - first in seconds and then in minutes - if “*” is
shown instead of numbers of minutes, means that the elapsed time
has exceeded 9999 minutes. The two lines after the TIME shows the
MOB position in Lat/Long.
PAGE
MOB Page 4: Data display will provide information of: Date, time
and position of MOB incident.
PAGE
Toggle between the four pages:
To turn MOB navigation off (two ways):
Either press [GOTO], [3] or... press [MENU, [4], [2].
To recall last MOB position, see section 8.2.
